Kitamura MyCenter 2XiF CNC Vertical Machining Center – 20,000 RPM, TSC Mill

Kitamura MyCenter 2XiF CNC Vertical Machining Center – 20,000 RPM, TSC Mill

Name: Kitamura MyCenter 2XiF CNC Vertical Machining Center – 20,000 RPM, TSC Mill
Brand: KITAMURA
SKU: 113664
Availability: InStock

Brand

KITAMURA

Location

Not specified

Specifications
Files & Videos

Disclaimer: All specifications and hours are approximate and for reference only, often based on manufacturer literature. Buyer must verify all details prior to purchase. Accessories shown are included only if listed on the invoice.

Equipment is sold AS-IS, WHERE-IS. All sales are final.

Features:
Fanuc 16iM CNC Control
20,000 RPM High-Speed Spindle
24 Station Automatic Tool Changer
Through Spindle Coolant
Daikin AKZ328-D142 Oil Cooling Unit
Fast Rapid Traverse
MPG Handwheel Control
Coolant Tank
Chip Conveyor
Books and Manuals
Levelling Pads

Travel:
X-Axis: 20.07 inch
Y-Axis: 13.97 inch
Z-Axis: 18.11 inch
Spindle Nose to Table (Min.-Max.): 6.3 inch – 24.4 inch
Rapid Traverse X Axis: 1,969 IPM
Rapid Traverse Y Axis: 1,969 IPM
Rapid Traverse Z Axis: 1,417 IPM
