Doosan Puma 2600SYII CNC Turn Mill Center – 2018 Bar Feeder, Sub Spindle, Y Axis Lathe

Brand
DOOSAN
Category
Lathes & Turning Machines
Type
Turning Centers
Model
Puma 2600SYII
Stock #
113578
Year
2018
Condition
Not specified

Location

Not specified
REQUEST FINANCING

Disclaimer: All specifications and hours are approximate and for reference only, often based on manufacturer literature. Buyer must verify all details prior to purchase. Accessories shown are included only if listed on the invoice.

Equipment is sold AS-IS, WHERE-IS. All sales are final.

Make: Doosan
Model: Puma 2600SYII
Year: 2018
Condition: Used – Excellent
Equipped With:
Fanuc Oi-TF Series CNC Control
Comes With LNS Quick Load Servo 80 S2 Bar Feeder
Royal Quick Grip 80 Collet Chuck Main Spindle
Royal Quick Grip 42 Collet Chuck Sub Spindle
Sub Spindle
Servo Controlled Full C-Axis on Both Spindles
12-Station (24 Positions) Live Tool Turret
Y Axis Capable
Tool Presetter
Parts Catcher
Parts Conveyor
LNS Fox Mist Collector
Additional Hard and Soft Jaws
Coolant System – 14 PSI Coolant Pump
Rigid Tapping on Both Spindles
Foot Operated Control for Chuck
Turbo Side Discharge Chip Conveyor with Chip Stripper bar
Misc. Tools Holders
Capacity:
Max Turning Diameter: 14.80″
Max Turning Length: 29.90″
Swing Over Bed: 30.70″
Swing over the Saddle: 24.80″
Max Bar Capacity: 3.20″
Travels:
X Axis Travel: 10.20″
Z Axis Travel: 32.70″
Y Axis Travel: 4.10″ (+ 2.10″ – 2.10″)
B Axis Travel: 32.70″ (Sub Spindle)
C Axis: 360° (0.001°) Both Spindle
Feedrate:
Rapid Traverse X Axis: 1181 IPM
Rapid Traverse Z Axis: 1181 IPM
Rapid Traverse Y Axis: 394 IPM
Rapid Traverse B Axis: 1181 IPM
Rapid Traverse C Axis: 200 RPM
Spindle:
Main Spindle Nose: A2-8
Main Spindle Bore: 3.60″
Main Spindle Bar Capacity: 3.20″
Main Spindle Speed: 4,000 RPM
Main Spindle Power: 30 HP
Sub Spindle:
Sub Spindle Nose: A2-5
Sub Spindle Bore: 2.40″
Sub Spindle Bar Capacity: 1.96″
Sub Spindle Speed: 6,000 RPM
Sub Spindle Power: 20 HP
Turret:
Capacity: 12 Stations (24 Positions
Turret Index Time: 0.15 Second
Live Tool Speed: 5,000 RPM
Live Tool Spindle Power: 10 HP
Tool Holders Type: BMT-65
General:
Power Source:  220v / 3-Phase / 60 Hz/ 57.08 kva
Overall Dimensions: 142″ x 75″ x 85″ High Approx.
Weight: 14,220 lbs Approx.
No files or videos to display
