NEW 32" X 160" GMC MODEL GML-32160 HEAVY DUTY PRECISION GAP BED LATHE

Brand

GMC

Not specified

NEW 32" X 160" GMC MODEL GML-32160 HEAVY DUTY PRECISION GAP BED LATHE

STANDARD EQUIPMENT

OPTIONAL EQUIPMENT

ALORIS type QC tool post set # 900-0051-500, 6 pcs .................. $1,850.00
15” large steady rest with roller jaws ................................... $1,850.00
Live Center # 900-0050-05 ............................................................ $195.00

SPECIFICATIONS

Max. swing over bed	32”
Max. length of workpiece	160”
Max. swing over cross slide	26-7/16”
Max. Swing in gap	46-1/2”
Width of Bed	16”
Effective length in gap to spindle	10”
Effective length in gap to chuck jaws	7”
Spindle bore	4-1/8” , D1-8
Taper of spindle center	MT#5 with1:20 reducing sleeve
Spindle speeds	25-1,600 rpm / 12 steps
Longitudinal feeds	0.0016-0.055 IPR, 60 kinds
Cross feeds	0.0008-0.027 IPR, 60 kinds
Inch threads	80-7/16”TPI, 54kinds
Metric threads	0.45-120 mm , 54 kinds
Module threads	0.25-60 mm, 46 kinds
Diameter pitch threads	60-0.25 DP , 42 kinds
Max. travel of top slide	9-1/8”
Max. travel of cross slide	16-1/2”
Longitudinal rapid traverse	18 ft / min.
Cross rapid traverse	8 ft / min.
Diameter of tailstock quill	3-1/2”
Max. travel of tailstock quill	9-1/4”
Taper of tailstock quill center	M.T. # 5
Max. weight of workpiece	2,000 LBS
4-way tool post size	1” x 1”
Longitudinal leadscrew diameter / pitch	Diameter: 3” Pitch: 2 TPI
Main Motor	15 HP, 220V/440V, 3 phase, prewired on 220V
Rapid traverse motor	1/3 HP, 220V/440V, 3 phase, prewired on 220V
Coolant pump motor	1/8 HP,220V/440V, 3 phase, prewired on 220V
Machine weight, approx.	11,950 LBS
Overall dimensions, LxWxH	225” x 48” x 67”
