DMC DL22LB CNC Lathe, 2019 - BRAND NEW IN CRATE

Name: DMC DL22LB CNC Lathe, 2019 - BRAND NEW IN CRATE
Brand: DMC
SKU: 53194
Availability: InStock

Brand

DMC

Location

Not specified

Specifications
Files & Videos

Overview

Type:

CNC Lathes

Manufacturer:

DMC

Model:

DL 22LB

Year:

2019

Stock #:

53194

Status:

For Sale

Description

DMC DL22LB CNC Lathe Fanuc 0iT Ctrl, 10" Chuck, 3.38” Spindle Bore, 3500rpm, 25hp, 14.96 Max Turn Length, 21.65 Max Swing, 15.35 Max Turn Dia., 12 Station Turret, 8.26” x 22.83” Travels, Tailstock, Programmable Quill, Chip Conveyor, Bar Feeder Interface, Tool Presetter, Parts Catcher, New 2019 *New in Original Crate, Located in California*

ImperialMetric

Swing	21.65"	549.91 mm
Max. Turning Length	20.87"	530.1 mm
Max. Turning Diameter	15.35"	389.89 mm
X-Axis	8.27"	210.06 mm
Z-Axis	22.83"	579.88 mm
Chuck Size	10"	254 mm
Bar Capacity	2.99"	75.946 mm
Spindle Bore	3.39 in
Spindle Nose	A2-8	A2-8
Power	25 hp	18.6 kW
Max RPM	3,500 RPM	3,500 RPM
Turret Stations	12	12
Dimensions	116.54" x 64.96" x 74.8"	116.54" x 64.96" x 74.8"
Weight	9,810 Lbs	9,810 Lbs

Fanuc 0i-T CNC Control
X/Z Box Way
Automatic (Servo) Tailstock
Programmable Quill
Chip Conveyor
Bar Feeder Interface
Tool Presetter
Parts Catcher

No files or videos to display

DMC DL22LB CNC Lathe, 2019 - BRAND NEW IN CRATE

Location

Specifications

Files & Videos

Overview

Description

Specifications

Equipped With:
