GML-1440HD, 14" x 40" Gap Bed Lathe with SINO DRO

1 year parts warranty for this model ISO 9001 certified Large spindle bore 2-1/16” Heavy Duty spindle D1-6 One-piece solid cast iron machine base Heavy Duty guideway width 10-1/4” Heavy Duty main motor 6 HP 16 spindle speeds from 45-1,800 rpm, speeds: 45/ 75/ 90/ 130/ 160/ 195/ 210/ 260/ 350/ 390/ 600/ 690 / 790 / 910/ 1,200/ 1,800 rpm 45 kinds of inch threads, and 39 kinds of metric threads Threading and feeding rate change without changing gears Spindle is balanced, hardened and precision ground Spindle is supported at 3-point by high precision bearings   All gears and shafts are hardened and precision ground Guideways induction hardened and precision ground Automatic lubrication system in headstock and feed box DISCLAIMER: : Please note this machine is incompatible with the use of a rotary phase converter. Any attempt to purchase, install, or employ one, whether carried out by you or a professional service company, will automatically void the warranty. It is crucial to understand that any such actions are entirely the responsibility of the buyer. This DISCLAIMER: is intended to clearly convey that the utilization of a rotary phase converter to power or operate this machine is not supported. Max. swing over bed 14 7/8" Max. length of workpiece 40" Max. swing over cross slide 10 1/16" Max. Swing in gap 23 1/4" Width of Bed 10 1/4" Effective length in gap to spindle 8 1/2" Effective length in gap to chuck jaws 3 1/2" Spindle bore 2 1/16" D1-6 Taper of spindle center M.T. #6 (MT6/MT4 sleeve) Spindle speeds 45-1,800 rpm / 16 steps Longitudinal feeds 0.0018-0.07 IPR, 42 kinds Cross feeds 0.0009-0.03 IPR, 42 kinds Inch threads 70-2 TPI, 45 kinds Metric threads 0.2-14 mm , 39 kinds Diametral Pitch threads 8-40 DP , 21 kinds Module threads 0.3-3.6 mm, 18 kinds Max. travel of top slide 4 1/4" Max. travel of cross slide 8 1/2" Spindle length w/o chuck 20 1/2 Diameter of tailstock quill 2 1/16"Max. travel of tailstock quillHeadstock size 5"16" x 17"Taper of tailstock quill center MT4 Main motor 6 HP, 220V/20A, 3 Phase Coolant pump 1/8 HP, 220V, 1 Phase Net weight 4,350 lbs. Overall dimensions, LxWxH 79" x 32.2" x 53" Free SINO DRO; Installed Free Taper turning attachment; Installed 8” 3-jaw chuck with one set reversible jaws 10” 4-jaw chuck 12” Face plate 5 1/2” large steady rest with roller jaws Oil pump on Apron for all guideways and leadscrews 2” follow rest Removeable gap 4-way tools post Foot brake Coolant system Halogen Work light Full length splash guard  (2) dead centers and (1) reducing sleeve MT6/MT4 Thread chasing dial Tool box and leveling pads For more complete information: https://www.gmcmachinetools.com/catalog
