GMC HEAVY DUTY PRECISION GAP BED LATHES - GML-2190T

GMC HEAVY DUTY PRECISION GAP BED LATHES - GML-2190T

Name: GMC HEAVY DUTY PRECISION GAP BED LATHES - GML-2190T
Brand: GMC
SKU: GML-2190T
Availability: InStock

Brand

GMC

Location

Not specified

Specifications
Files & Videos

Made in Taiwan-100% made in Taiwan, by top manufacturer with very high level of quality
1 year industrial warranty for parts for all Taiwan lathes
One piece solid casting base, Meehanite high performance cast iron
Machine bed is made of Meehanite casting – high performance cast iron
ISO 9001 certified
Large spindle bore 3-1/8”
Heavy Duty spindle D1-8
Heavy Duty guideway width 12”
Spindle speeds from 40-2,000 rpm, 12 speeds
Threading and feeding rate change without changing gears
Spindle is balanced, hardened and precision ground
Spindle is supported at 3-point by high precision bearings
All gears and shafts are hardened and precision ground
Guideways induction hardened and precision ground

Automatic lubrication system in headstock and feed box

DISCLAIMER
Please note this machine is incompatible with the use of a rotary phase converter. Any attempt to purchase, install, or employ one, whether carried out by you or a professional service company, will automatically void the warranty. It is crucial to understand that any such actions are entirely the responsibility of the buyer.

This disclaimer is intended to clearly convey that the utilization of a rotary phase converter to power or operate this machine is not supported.

Max. swing over bed	20-1/2” 20-1/2”
Max. length of workpiece	60”	90”
Max. swing over cross slide	13” 13”
Max. Swing in gap	29-1/8” 29-1/8”
Width of Bed	12”
Effective length in gap to spindle	6”
Effective length in gap to chuck jaws	3-1/2”
Spindle bore	3-1/8” , D1-8
Taper of spindle center	M.T.# 6 w/ reducing sleeve MT6/MT5
Spindle speeds	40-2,000 rpm / 12 steps
Longitudinal feeds	0.002-0.03 IPR, 35 kinds
Cross feeds	0.0008-0.011 IPR, 35 kinds
Inch threads	4-56 TPI, 36 kinds
Metric threads	0.5-7.0 mm ,17 kinds


Max. travel of top slide	5”
Max. travel of cross slide	11”
Spindle length w/o chuck	17”
Leadscrew length X TPI	1-1/4” x 4 TPI
Diameter of tailstock quill	2-3/4”
Max. travel of tailstock quill	5-7/8”

Taper of tailstock quill center	M.T. #4

Main motor	7-1/2HP, 220V or 440V, 3 phase
Amperage Draw	220V/ 35A , 440V/20A
Coolant pump motor	1/8 HP, 220V, or 440V, 3 phase, 2Gal coolant
Machine Oil	# 30 weight Machine oil, 5 Gallons
Machine weight, approx. LBS	4,150 LBS	5,150 LBS
Overall dimensions, LxWxH Shipping dimensions: LxWxH	105” x 41” x 59” 110” x 38” x 66”	139” x 41” x 59” 140” x 38” x 66”
