CAPACITY:

Table Diameter 196.85"
Turning Diameter 236.22"
Maximum Turning Height 98.42"
Maximum Stroke of Vertical Rams 59.05"
Ram Cross Section 13.77" x 13.77"
Cross Rail Travel 47.24"
Ram Saddle Travel, X-Axis 175"
Turning Tool Capto C8
Table Load Capacity 264,000 lbs.
Table Speed Ranges, Max 0-60 RPM
Table Indexing .001
Main Motor, 2X 108 HP (81 KW)
Milling Spindle Taper HSK-A100
Milling Spindle Speeds, Max 0-3,000 RPM
Milling Spindle Motor 49 HP (37 KW)
Machine Footprint 626" x 484"
Machine Height 315"
Machine Weight 550,000 lbs

Equipped With:

Siemens 840DE SL CNC Control
12-Position Automatic Tool & Attachment Changer
40-Station Automatic Tool Magazine
Hydrostatic Table
Vertical Ram with Milling Spindle
Vertical Milling & Drilling Attachment
Right Angle Milling Attachment
Universal Milling Attachment
Through Spindle Coolant & Flood Coolant
Dual Dive 108 HP (81 KW) Table Motors
High Resolution Heidenhain Scales & Encoder
Renishaw RMP 60 Probe
Renishaw NC-4 Milling Tool Probe
Full Machine & Operator Enclosure
Chip Conveyor


Note:

Brand New, In Stock for Immediate Delivery!!
Additional Details Upon Request!
