CAPACITY:

Table Diameter 98.42"
Turning Diameter 118.11"
Maximum Turning Height 78.74"
Maximum Stroke of Vertical Rams 59.05"
Ram Cross Section 9.84" x 9.84"
Cross Rail Travel 47.24"
Ram Saddle Travel, X-Axis 59.05"/78.74" (-/+)
Table Travel, Y-Axis 118.11"
Turning Tool AF 40x40
Table Load Capacity 77,000 lbs
Table Speed Ranges, Max 0-180 RPM
Table Indexing .001
Main Motors, 2X........................ 59 HP (44 KW) 59 HP (44 KW)
Milling Spindle Taper SK 50
Milling Spindle Speeds, Max 4,000 RPM
Milling Spindle Motor 54 HP (41 KW)

Equipped With:

Siemens 840D SL CNC Control
6-Position Automatic Attachment Changer
40-Station Automatic Tool Magazine
Hydrostatic Table
Vertical Ram with Milling Spindle
Vertical Milling & Drilling Attachment
Right Angle Milling Attachment
A-Axis Sweep Milling Attachment
Through Spindle Coolant & Flood Coolant
Dual Dive 59 HP (44 KW) Table Motors
Dual Gear Boxes with Dual Range Speeds
High Resolution Heidenhain Scales & Encoder
Work Piece Probe
Milling Tool Calibration Device
Turning Tool Calibration Device
Full Machine & Operator Enclosure
Full Closed Video Monitoring Circuit
Roto Clear Window
Chip Conveyor


Note:

Brand New, In Stock for Immediate Delivery!!
Additional Details Upon Request!
