Maximum Wire Diameter: .060"
Maximum Spring Diameter: .480" Maximum Spring Length: 3.20" Camshaft Characteristics: Min. Increment: Plus or Minus 0.1 Degrees Max. Increment: Plus or Minus 359.9 Degrees Max Speed: 100 rpm Wire Feed Characteristics: Min. Increment: Plus or Minus .002" Max. Increment Plus or Munus 400" Max. Feed Speed: 2400" per min. Memory: 235 steps per program, Program Storage: 200 program 3.5" floppy disk Power:Wire Feed 800W, Camshaft 800W Power Consumption: (200v/3/60) 10A DIMENSIONS: 63" x 39" x 22" Weight: 1630 lbs. Equipped with: 4 T Slides 1 Cut Slide Cast Disc Jog Button 65810 hrs. No Straightener |
