16" (406MM) 5500 US TON TAIYUAN ALUMINUM EXTRUSION PRESS LINE

CONSISTING OF ;

1. COLD BILLET SAW, YEAR 2007 KOREAN MADE

2. BILLET HEATER FOR SHORT BILLET-GAS HEATED, YEAR 2007 KOREAN MADE

3. EXTRUSION PRESS, YEAR 2007 TAIYUAN IN CHINA

TYPE : FRONT LOADING

CAPACITY : 50MN

BILLET DIAMETER : 11 AND 16

MAX. BILLET LENGTH : 1,200 MM

DIE STACK : 850 MM IN DIA, 900 MM IN LENGTH

PLC : SIMENS S7

MAIN PUMP : 3 EA OF VARIABLE PUMPS AND 3 EA OF FIXED PUMPS

4. HANDLING EQUIPMENT LINE, YEAR 2007 KOREAN MADE

PLATEN SAW

WATER QUENCH

SINGLE PULLER

2 MAN STRETCHER 450 TON

FINAL SAW (PROFILE SAW)

BELT TABLES

5. DIES HEATER
REMARKS: 1. MANUAL FOR MECHANICAL PARTS IS MISSING BUT HYDRAULIC SCHEME AND ELECTRIC DRAWING IS AVAILABLE. THIS PRESS IS DESIGNED FOR EXTRUDING BOTH 11 AND 16 BILLET. BUT WE RECOMMEND EXTRUDING 14 BILLET WITH MODIFICATION OF STEM AND CONTAINER.
