Doosan Puma 2600SYII CNC Lathe – 2021 C Axis Live Tooling, Sub Spindle, Y Axis

Brand
DOOSAN
Category
Lathes & Turning Machines
Type
Turning Centers
Model
Puma 2600SYII
Stock #
113607
Year
Not specified
Condition
Not specified

Location

Not specified

*All specifications and hours are approximate and for reference only, often based on manufacturer literature. Buyer must verify all details prior to purchase. Accessories shown are included only if listed on the invoice.

Make: Doosan
Model No.: Puma Series
Condition: Used – Good
Equipped With:
Doosan-Fanuc i-Plus Series CNC Control
10″ 3-Jaw Chuck on Main Spindle
8″ 3-Jaw Chuck on Sub Spindle
Sub Spindle
Sub Spindle Parts Ejector
Servo Controlled Full C-Axis on Both Spindles
12-Station (24 Positions) Live Tool Turret
Y Axis Capable
Tool Presetter
Parts Catcher
Parts Conveyor
Bar Feeder Interface
MP Systems VR8 High Pressure Coolant
Coolant Tank
LNS Chip Conveyor
Rigid Tapping on Both Spindles
Foot Operated Control for Chuck
Capacity:
Max Turning Diameter: 14.80″
Max Turning Length: 29.90″
Swing Over Bed: 30.70″
Swing Over Saddle: 24.80″
Max Bar Capacity: 3.20″
Travels:
X Axis Travel: 10.20″
Z Axis Travel: 32.70″
Y Axis Travel: 4.10″ (+2.10″ / -2.10″)
B Axis Travel: 32.70″ (Sub Spindle)
C Axis: 360° (0.001°) Both Spindles
Feedrate:
Rapid Traverse X Axis: 1,181 IPM
Rapid Traverse Z Axis: 1,181 IPM
Rapid Traverse Y Axis: 394 IPM
Rapid Traverse B Axis: 1,181 IPM
Rapid Traverse C Axis: 200 RPM
Main Spindle:
Main Spindle Nose: A2-8
Main Spindle Bore: 3.60″
Main Spindle Bar Capacity: 3.20″
Main Spindle Speed: 4,000 RPM
Main Spindle Power: 30 HP
Sub Spindle:
Sub Spindle Nose: A2-5
Sub Spindle Bore: 2.40″
Sub Spindle Bar Capacity: 1.96″
Sub Spindle Speed: 6,000 RPM
Sub Spindle Power: 20 HP
Turret:
Capacity: 12 Stations (24 Positions)
Turret Index Time: 0.15 Second
Live Tool Speed: 5,000 RPM
Live Tool Spindle Power: 10 HP
Tool Holders Type: BMT-65P
General:
Power Source: 220V / 3-Phase / 60 Hz / 57.08 kVA
Overall Dimensions: 142″ x 75″ x 85″ High Approx.
Weight: 14,220 lbs Approx.
No files or videos to display

Want to request a quote from the owner of this listing?
