Haas ST-15Y CNC Lathe – 2024 Y-Axis, Live Tooling, Only 4 Cutting Hours

Disclaimer: All specifications and hours are approximate and for reference only, often based on manufacturer literature. Buyer must verify all details prior to purchase. Accessories shown are included only if listed on the invoice.

• Features:

• Haas CNC Control
• Visual Part Programming System
• User Definable Macros
• Early Power-Failure Detection Module
• Rigid Tapping
• Spindle Orientation
• Haas Connect: Remote Monitoring
• Media Display
• 1GB Max Memory
• Ethernet Interface
• WiFi Connection For Haas Control
• Inch Measurement Units
• Coolant Tank

• Capacity:

• Max Turning Diameter : 11.0″
• Max Swing Over Bed : 16.5″
• Max Turning Length: 16.0″
• Max Bar Capacity : 2.5″

• Travels:

• X Axis Travel : 7.88″
• Y Axis Travel : ± 2.0″
• Z Axis Travel : 16.00″
• C Axis : 0.001 Degree

• Feedrate:
• Rapid Traverse X Axis: 472 IPM
• Rapid Traverse Y Axis: 472 IPM
• Rapid Traverse Z Axis: 1200 IPM

• Spindle:

• Spindle Nose: A2-6
• Spindle Bore: 3.5″
• Spindle Speed: 4000 RPM
• Spindle Motor: 20 HP

• Turret:

• Turret Capacity: 12 Stations
• Live Tool Speed: 4000 RPM
• Turret Type: BMT-45

• General:

• Air Requirement: 4 scfm @ 100 psi
• Machine Dimensions: 126″ x 70.0″ x 81.0″ High
• Machine Weight:7,900 lbs Approx.
