26 x 160" Metal Lathe with 2-Axis DRO

ISO 9001 certified Large spindle bore 4-1/8” Heavy Duty spindle D1-8 4-way rapid traverse on carriage Heavy Duty guideway width 16” Heavy Duty main motor 15HP 16 spindle speeds from 25-1,600 rpm, 16 speeds 54 kinds of inch threads, and 54 kinds of metric threads Threading and feeding rate change without changing gears Spindle is balanced, hardened and precision ground Spindle is supported at 3-point by high precision bearings   All gears and shafts are hardened and precision ground Guideways induction hardened and precision ground Automatic lubrication system in headstock and feed box One year industrial  warranty for parts Please note this machine is incompatible with the use of a rotary phase converter. Any attempt to purchase, install, or employ one, whether carried out by you or a professional service company, will automatically void the warranty. It is crucial to understand that any such actions are entirely the responsibility of the buyer. This DISCLAIMER: is intended to clearly convey that the utilization of a rotary phase converter to power or operate this machine is not supported. Max. swing over bed 26" Max. length of workpiece 160" Max. swing over cross slide 17 1/4" Max. Swing in gap 35 3/8" Width of Bed 16" Effective length in gap to spindle 9" Effective length in gap to chuck jaws 4 1/2" Spindle bore 4 1/8" D1-8 Taper of spindle center M.T. #5 Spindle speeds 25-1,600 rpm / 16 steps Longitudinal feeds 0.0016-0.055 IPR, 25 kinds Cross feeds 0.0008-0.027 IPR, 25 kinds Inch threads 80-7/16 TPI, 54 kinds Metric threads 0.45-120 mm , 54 kinds Diametral Pitch threads 7/8-160 DP , 42 kinds Module threads 0.25-60mm, 46 kinds Max. travel of top slide 9" Max. travel of cross slide 14 1/2"Spindle length w/o chuckLeadscrew length X TPI 20 1/2"1 1/2" x 2 TPIDiameter of tailstock quill 3 1/2"Max. travel of tailstock quill 9 1/4"Taper of tailstock quill center MT5Main motorRapid traverse motor 15HP, 220V/40A or 440V/20A, 3 phase1HP, 220V or 440V, 3 phaseCoolant pump 1/8 HP, 220V, or 440V, 3 phase Net weight 10,850 lbs. Overall dimensions, LxWxH 227" x 46" x 72" For more complete information: https://www.gmcmachinetools.com/catalog
