EPC Power Corp PD500 Inverter, 2023
Brand
Category
Model
PD500
Stock #
829052
Year
2023
Condition
Not specified
Location
Not specified
|
Power Rating: 250-500kW
AC Expoert/Import: Up to 500kW
AC Voltage Range: 208, 350, 400, or 480V RMS
Frequency: 50 or 60Hz, configurable
Peak DC→AC Efficiency: 98.4%
DC Input Voltage Range: 310–1250 VDC
Max DC current: 750 A
Power factor: –1 to +1, full four-quadrant reactive power control
Enclosure Size: 26.4″ × 20.9″ × 41.1″
Weight: ≈725lbs
Cooling: Liquid, 30–50 % ethylene- or propylene-glycol water
All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Certifications: UL 1741SA/SB, IEEE 1547, IEC 62477-1, VDE, AS4777.2 All specifications are assumed to be correct but must be confirmed by the purchasing entity. |
