50 TON DAKE MODEL #26-262 HYDRAULIC 4 POST PRESS 14" STROKE: YOBRO #24085

Name: Used DAKE 26-262 For Sale 24085
Brand: DAKE
SKU: 24085
Availability: PreOrder

Brand

DAKE

Location

Ohio

REQUEST FINANCING

Specifications
Files & Videos

Serial no. 147464
Model 26-262
4 post downstroke type; floor standing
Distance between 3" diameter posts: 30" L-R x 20" F-B
Area of bed (nominal): 30" L-R x 29" F-B
Overall dimensions of bed: 40" L-R x 29" F-B
Bed bolsters: (1) 29" L-R x 29" F-B x 2" thick (1) 27" L-R x 27" F-B x 2" thick
Area of slide (nominal): 30" L-R x 29" F-B
Overall dimensions of slide: 40" L-R x 29" F-B
Stroke of fully guided slide: 0 - 14" maximum
Daylight opening (total): 28" maximum
Daylight opening (over bolsters): 24" maximum
Main ram diameter: 5"/4" @ 5095 PSI - 50 tons
Floor to top of bed: 36"
Power unit (top rear of press): (2) hydraulic pumps, both driven by 7-1/2 HP 1745 RPM 220/440/3/60 motor

Speeds approx.:
180"/minute closing
5"/minute pressing to 50 tons
430"/minute return

Controls:
Pushbutton operation w/stroke & pressure control
PLC
Pressure gauge
