12" x 24" Okamoto Accugar 124N Surface Grinder
Brand
Category
Type
Model
Not specified
Stock #
55
Year
Not specified
Condition
Not specified
Location
Not specified
|
Magnetic Chuck Surface: 12″ x 24″ Distance Under 12″ Grinding Wheel to Table Top: 13.7″ Table Travel: 29.5″ (Longitudinal) 13.6″ (Cross) Pad Size: 30″ x 11.8″ Table Longitudinal Feeds: 1 – 100 FPM (Hydraulic) 1.85″ (Hand) Table Cross Movement: .2″ – .8″ (Hydr. Intermited) 4 – 40 IPM (Hydr. Continuous) .25″ (Hand, per Revolution) .001″ (Graduation of Handweel) Spindle Vertical Movement: .001″ – .015″ (Auto Feed per Table Stroke) .05″ (Hand Feed per Revolution) .0001″ (Graduation of Handwheel) Vertical Rapid Feed: 19 IPM Grinding Wheel Size: 12″ O.D. x 1.5″ Width x 5″ I.D. Spindle Speed: 1800 RPMWeight
5000 lbs
Dimensions
71 × 93 in
|
