Berthiez Ø 6300 mm CNC

Brand

BERTHIEZ

Location

Not specified

REQUEST FINANCING

Specifications
Files & Videos

Located in Deinze, Belgium

Technical information

Chuck dia. 3300 mm
Max turningdia -- passage 6300 mm
Power on the spindle 75 kW
Max hight of workpiece Z-axis 2600 mm
Command Siemens 840D
Number of speeds 13 / 36 / 100 rpm
Weight 93 ton
TOOLING yes

Additional info

Type: 9375
Retrofitted in 2017 with Siemens 840D

- max diameter to be turned to centre: 6100 mm
- max workpiece height under arm: 2700 mm
- vertical travel of ram: 1250 mm
- vertical travel of toolhead: 1250 mm
- horizontal travel of blue toolhead: 2485 mm
- swivel angle or tool head: 45° + 30°
- turntable is movable in order to accommodate workpieces up to 6 meters in diameter
- max load on table: 50 tons
- power on table: 75 kW
- 3 variable speeds of table (CNC controlled): 1 > 13 rpm / 14 > 36 rpm / 37 > 100 rpm
- positioning of the table is done by two buttons, once the correct position is reached the position can be nulled on the digital readout
