12,000 lbs. x 24" x .375" Coe Press Equipment Coil Cradle Straightener, Heavy-Duty Model # CPCC-12024 and CPPS-500-24
Brand
Category
Model
Model # CPCC-12024 and CPPS-500-24
Stock #
2927
Year
Not specified
Condition
As-Is
Location
Michigan
| Coil Weight | 12000 pounds |
| Coil Width | 24 inches |
| Coil Thickness | .375 inches |
|
Heavy Duty Coe Press Equipment Coil Cradle Straightener
Model CPCC-12024 & CPPS-500--24 Serial Number - D111448 12,000 lbs. Maximum Coil Weight 24" Maximum Coil Width 72" Maximum Coil O.D. .375" Maximum Stock Thickness @ 24" Width Right To Left Feed Direction Equipment and Features (5) 5" Diameter Straightening Rolls Air Operated Entrance and Exit Threading Roll - 8" Bore Cylinders 6" Diameter Nest Rolls with 3" Journals Heavy Duty Design 5" Bore Air Operated Stock Peeler 3" Thick Adjustable Side Plates with Rolls Central Lubrication System 14' Material Deflector 20 H.P. Variable Speed Drive Jog, Forward and Reverse Remote Pendant Jog Control Air Operated Material Ramp and Extension Model CPMD-12024 15-45 FPM Pay Off Rate Exit Vertical Edge Guides Independently Adjustable Breaker Rolls Loop Control Arm - Automatic Operation Can be seen under power in the S&G Press Livonia Warehouse! More Heavy Capacity Coil Cradle Straighteners For Sale at S&G Press Heavy Duty Coe Press Equipment Coil Cradle Straightener - Coil Feed Equipment For Sale Coe Heavy Duty Coil Cradle Straighteners are engineered for demanding environments, providing exceptional material handling for thick gauge coils. Their robust design ensures superior straightening, minimizing downtime and maximizing precision. This results in increased production efficiency and consistently high-quality output. Specifically, Reverse Loop Coil Cradle Straighteners enhance safety when processing thick, high-strength materials by managing coil tension and preventing uncontrolled material movement. |
|
