Toshiba BTD-110R16 CNC Horizontal Table Type Boring Mills, 1999

Name: Used JIANGHAI BTD-110R16 For Sale 51182
Brand: JIANGHAI
SKU: 51182

Brand

JIANGHAI

Location

Not specified

REQUEST FINANCING

Specifications
Files & Videos

Overview

Type:

Horizontal Table Type Boring Mills

Manufacturer:

TOSHIBA

Model:

BTD-110R16

Year:

1999

Stock #:

51182

Status:

For Sale

Specifications

ImperialMetric

Spindle Size	4.3"	109.22 mm
X Axis - Table Travel	78.7"	1,999 mm
Y Axis - Vertical Head Travel	59"	1,498.6 mm
Z Axis - Spindle Travel	57"	1,447.8 mm
W Axis - Quill Travel	19.6"	497.84 mm
B Axis - Table Rotation	0.0001°	0.0001°
Table Dimensions	55" x 65"	55" x 65"
Power	40 hp	29.8 kW
RPM	3,000 RPM	3,000 RPM
Max Table Load	13,860 lb	6,286.8 kg
Tool Changer Capacity	30	30
Machine Dimensions	202" x 242.5"	202" x 242.5"

Equipped With:

Tosnuc 888 CNC Control
Coolant Thru Spindle
Partial Enclosures
Data Server
Shape Contouring Software
