Range of Measurements: Linear Range (Diameter): 200 m (with selected targets), 160 m (525 ft with 80m target)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,System Performance: Azimuth Range: ± 320º (640º end to end) Elevation Range: + 79º / -59º Angular Resolution: ± 0.018 arc seconds System Angular Accuracy: 3.5 μm/m* System Resolution: 0.02 arc seconds Maximum Lateral Target Speed: 180º / sec Maximum Acceleration: > 2 g Maximum Battery Life: 6 hours (internal battery, Capable of hot-switching with External battery) Internal Level Accuracy: ±2 arc-second Internal Level Range: ±2 degrees

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,ADM2: IR Laser (ADM-Maxx™): Class I (eye safe) Accuracy: ± 25 μm or 1.5 μm/m* (which ever is greater) Resolution: 0.1 μm

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Environmental: OperatingTemperature: -10º C to > 45º C Storage Temperature: -10º C to 60º C Barometric Pressure: 8 mmHg – 825 mmHg Relative Humidity: 10-95% non-condensing Altitude: -700 m – 3000 m

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Autolock (Automated Target Search): Full Range Pointing Accuracy: 2” Field Of Vision: ±12.5º (diagonal)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Dimensions: Tracker Weight: 10.9 kg (24 lb) Tracker Size: Height: 43 cm (16.95 inches) Width: 19.8 cm (7.8 inches)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Equipped With: 1.5″ Standard SMR 0.5″ Standard SMR 1.5″ Precision SMR 50mm Scribe Tip 50mm w/3mm Ruby Tip 100mm w/3mm Ruby Tip 100mm Carbon Fiber Ext. 1.5″ Relocation Nests Calibration Tripod Standard Toolkit Brunson Tracker Stand

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
