Seibu MM75UP "Ultra Precision Wire EDM

High Speed-High Precision

Seibu’s MM75UP "Ultra Precision" Wire EDM is built for the ultimate in wire EDM precision. The machine is designed to deliver high material removed rates while holding a pitch accuracy of ±1 micron. Machine castings are ground and hand scrapped for complete flatness. Guideways are checked for flatness lasered for straightness and test cuts are performed on all machines which are then checked on a CMM for accuracy resulting high precision parts. The MM75UP "Ultra Precision" Wire EDM features the user-friendly Seibu Smart NC Control (Fanuc Drives/Control) series control with a 21.5-inch TFT LCD touchscreen that contains over 4000 cutting conditions. The GUI for Windows graphical interface makes it easy for operators to learn the control. The control has been customized to show more information so operators can check the necessary cutting data or maintenance work on any screen at any time. The control has been customized to show more information so operators can check the necessary cutting data or maintenance work on any screen at any time. Seibu Smart NC Control (Fanuc Drives/Control) There is Seibu Control consistency across all models of Seibu wire edms.

Specifications

X, Y, Z axis travel	29.5” x 19.7” x 11.0”
Max. workpiece weight	2204 lbs.
Max. workpiece dimensions WxDxH	35.4” x 27.5” x 10.6”
Wire diameter	.002" to .012"
Automatic wire threader	AWF-4
U-V axis travel UxV	±2.4” × ±2.4”
Max.taper angle	±10° @ 10.6”
Max.taper angle	（±45°/1.6”： option)
Machine Dimensions WxDxH	115.9” x 108.0” x 85.4”
Machine Weight	11,243 lbs.

Selling Features

• 100% made in Japan
• hand scraped meehanite castings
• Seibu Smart NC Control (Fanuc Drives/Control)
• air cooled cabinets
• 17" dry annealing auto. wire feeder
• absolute glass scale feedback
• core stitch circuit
• super fine finish circuit
• anti-electrolysis circuit
• corner control
• workpiece straightness circuit
• different height software
• hardened insulated work table
• vertical worktank door with signal lights
• worktank sensors
• automatic water level control
• LED worktank light
• remote control handbox
• dielectric chiller
• prefilter
• 4 MAN Triple bellow paper filters (Filters Sit out of Water with Air Blow Out)
• 2 DI bottles
• wire alignment block
• tool box

Optional Items
• 45° taper
• EL coating
• rotary table
• thermal adjust 24
• small hole attachment device
• 20kg wire spooler

Specifications are subject to change without prior notice.
