CAPACITY:
Tonnage Capacity 67 Tons
Maximum Bending Length 82"
Distance Between Housings 69"
Stroke Length 8"
Throat Depth 16.5"
Travel In X-Axis (Back Gauge Range) 20"
Speed of Travel in X-Axis 827 IPM
Travel In R-Axis (Back Gauge Up/Down) . 13"
Press Speed (Rapid Advance) 236 IPM
Press Speed (Bending) 47 IPM
Press Speed (Return) 472 IPM
Main Motor 10 HP
Overall Dimensions 96" x 65" x 95"
Overall Weight 10,780 Lbs.



Equipped With:
Delem DA-65TW 6-Axis CNC Control
4-Axis CNC Back Gauge (R-1, X-1, Z-1, Z-2)
4-Cylinder Ram Drive
Full Set Of Upper Quick Clamp Tool Holders (Bolted to Machine)
Crowning System
Electric Foot Switch


NOTE: Inspect In Plant Under Power
