CAPACITY:

Spindle Diameter 5.12"
Spindle Taper BT #50
Vertical Head Travel, y 78.74"
Table Travel, x 118.11"
Column Travel, z 55.11"
Spindle Travel, w 27.55"
Spindle Center to Table Surface 0.98"-77.75"
Spindle Nose to Table Center 2.75"-85.43"
Built in Rotary Table 62.99" x 70.86"
Table Index 0.001 Degree
Table Load Capacity 22,000 LBS
Rapid Traverse:

x,y,z Axis 393.70 IPM
Feed Rates:

x,y,z Axis 393.70 IPM
Spindle Speeds (2 Ranges) 35-3000 RPM
Approximate Floor Space 375" L x 335" W x 186" H
Approximate Weight 93,100 LBS

Equipped With:

FANUC 32iB Plus CNC Control w/ 10.4" LCD Display
Built-In "B" Axis Rotary Table (Positioning)
60 Position Automatic Tool Changer (BT #50)
Linear Scale for X/Y/Z Axes
Oil Chiller for Gear Box
Spindle Extension Sleeve
Spindle Vibration Supervision Function
Auto Power Off
Auto Central Lubrication System
Spindle Sleeve Extension
Thru Spindle Coolant (20 Bar)
Chip Auger For Table & Chip Conveyor
29 HP/ 40 HP Spindle Drive Motor 220/3/60
Meehanite Cast Iron Construction
Roller Type Linear Guide Ways on X/Z Axis
Box Ways on Y Axis

Note:


1 Year Parts Warranty on Machine
2 Year Parts on the Fanuc Control

Note:


Machine in Stock and Ready to Ship from Manufacturer
