1500MM ANDRITZ SKIN PASS MILL
Brand
Category
Type
Model
Not specified
Stock #
116064
Year
Not specified
Condition
Used
Location
Not specified
|
MFG. DATE: 1989, REINSTALLED 2004
MATERIAL: COLD ROLLED, HOT ROLLED PICKLED, GALVANIZED, ELECTROGALVANIZED NON-
OILED
ENTRY
MAX. THICKNESS: 3.05 MM
MIN. THICKNESS: 0.45 MM
MAX. WIDTH (HARD-HARNESSED): 1605 MM X 1.5 MM
MIN. WIDTH: 700 MM
MAX. SECTION (WIDTH X THICKNESS): 4 500 MM2
MAX. WEIGHT OF COIL: 30 TONS
COIL ID: 610 MM
WITH LEAFS: 740 - 780MM
COIL MAX. OUTSIDE DIAMETER: 1 900 MM
COIL MIN. OUTSIDE DIAMETER: 1 000 MM
EXIT
INTERNAL DIAMETER: 610 MM
MAX. OUTSIDE DIAMETER: 1 880 MM
MIN. OUTSIDE DIAMETER: 1 000 MM
MAX. WEIGHT: 30 TONS
OILING CAPACITIES: 1 TO 3.9 GSM/2 SIDES
ELONGATION: 0.2 TO 2.0%
MAX. SPEED: 300 M/MIN
HYDRAULIC SCREWS: BOTTOM
WORKROLL: 380/425MM DIA
BACK-UP ROLL: 780/850MM DIA
MAIN MOTOR: DC VOLT
TOTAL POWER REQUIRED: 2000 KVA
DRAWINGS, MECHANICAL & ELECTRICAL AVAILABLE
|
