Maximum Rated Work Diameter | 14” |
Maximum Travel Hob Slide | 15” |
Maximum Distance Work Spindle Face to Tail Center | 27.25” |
Work Spindle Face to C/L of Hob Spindle Maximum | 18.5” |
Work Spindle Face to C/L of Hob Spindle Minimum | 3.5” |
C/L of Work Spindle to C/L of Hob Spindle Maximum | 9.25’ |
C/L of Work Spindle to C/L of Hob Spindle Minimum | 2” |
Distance of C.L of Work Spindle to Bottom of Overarm | 7.25” |
Maximum Hob Diameter | 6.25” |
Maximum Swivel Setting | 50 Degrees |
Hob Speed Range | 64-362 RPM |
Work Spindle Speed | 5 IPM |
Work Spindle Taper | No. 18 B&S |
Approximate Weight | 9,500 Lbs. |
EQUIPPED WITH: |
