Mazak Optiplex 3015 6kW 2013
Brand
Category
Type
Model
Optiplex 3015
Stock #
100333
Year
2013
Condition
Very Good
Location
Not specified
| Sheet-W | 60 inches |
| Sheet-L | 120 inches |
| Wattage | 6000 watts |
| X-Travel | 60 inches |
| Y-Travel | 120 inches |
| Control | Mazak Preview 2 |
| Power | 4.0 Kw (Co2) |
| Machine Structure | Flying Optics |
| Motion Drive Sys. | X, Y Axis Rack & Pinion |
| Motion Drive Sys. | Z-Axis Belt Drive |
| Max Proc. Feedrate X, Y Axis | 2,362 Ipm |
| Rapid Travel Speed (X,Y) | 4,724 Ipm |
| Memory Capacity | 16 G |
| Number Of Control Axis | 3 |
| Program Input System | EIA/ISO |
| Position Detection System | Encoder |
| Minimum Command Unit | 0.0001" |
| Position Accuracy | ±0.003 mm |
| Max Cut Mild Steel | 1.00" |
| Max Cut Stainless Steel | 0.590" |
| Max Cut Aluminum | 0.472" |
| Max Workpiece Weight | 2,050 Lbs |
| Work Table Height | 35.43" |
| Total Electrical Requirement | 51 KVA |
|
Equipped With: Panasonic 6000 Watt Resonator Eia/Iso Program Input System 16 G Memory Capacity |
|
