Sheet-W | 60 inches |
Sheet-L | 120 inches |
Wattage | 4000 watts |
X-Travel | 60 inches |
Y-Travel | 120 inches |
Control | Mazak Preview 2 |
Power | 4.0 Kw (Co2) |
Machine Structure | Flying Optics |
Motion Drive Sys. | X, Y Axis Rack & Pinion |
Motion Drive Sys. | Z-Axis Belt Drive |
Max Proc. Feedrate X, Y Axis | 2,362 Ipm |
Rapid Travel Speed (X,Y) | 2,362 Ipm |
Memory Capacity | 16 G |
Number Of Control Axis | 3 |
Program Input System | EIA/ISO |
Position Detection System | Encoder |
Minimum Command Unit | 0.0001" |
Position Accuracy | ±0.003 mm |
Max Cut Mild Steel | 1.00" |
Max Cut Stainless Steel | 0.500" |
Max Cut Aluminum | 0.375" |
Max Workpiece Weight | 2,050 Lbs |
Work Table Height | 35.43" |
Total Electrical Requirement | 51 KVA |
Equipped With: Panasonic 4000 W Resonator Eia/Iso Program Input System 16 G Memory Capacity |
