16" (406mm) Ebner Vertical Bright Anneal Furnace w/Alkaline Strip Cleaning Entry   Our stock number: 114405


Ebner Bright Anneal Furnace:
Manufacturer - Ebner
Model - B6V6 80/1350 Vertical Strip Annealer
Year - 1996
Type - Vertical Bright Anneal Strip Annealing line
Min/Max Width Capacity: 7.875" to 16" (200mm to 406mm)
Thickness Capacity: .004" to .060" (.102mm to 1.524mm)
Max thickness Capacity at 13" (330mm): 0.070" 1.778mm at 330mm)
Speed - 5 to 50 Meter/Min
Temp Deg. - 750c to 1170c
Hess Engineering Bridle Roll Assembly, S/N 1262
Carry over table to vertical entry and exit Accumulator
8 Steering rolls
Dancer rolls into Hess-Sundwig Coil Winder
20" (508mm) solid block x 18" (457mm) wide
Belt Wrapper with 40 HP DC Drive
Ebner Furnace, Ebner Jet Cooler, Ebner Controls
Natural Gas Fired - 100% Hydrogen Atmosphere
Adco - 7-1/2 ton Bridge Crane

Nisterhammer Westerwald Alkaline Strip Cleaning Section:
Manufacturer - Nisterhammer Westerwald
Maximum Strip Width - 16" (406mm)
Thickness Capacity: .004" to .060" (.102mm to 1.524mm)
Min/Max Width Capacity: 7.875" to 16" (200mm to 406mm)
Speed - 5 to 50 Meter/Min
Hess Engineering Paper Winder S/N 1256
Hess Sundwig Uncoiler with 10 HP DC Drive
In Line Pinch Rolls
Jib Crane with 1/2 Ton Electric Hoist
In Line Spot Welder
8 Stand Brushing Unit with:
Pre-Cleaning, Post Cleaning, Rinse section and Forced Air Dryer, Pumps,

Controls, Filter and Operator Control Panel
