Title: 1000 TON WILLIAMS & WHITE 96" X 48" BED 4-POST HYDRAULIC PRESS: STOCK# 15313
Type: Presses, Hydraulic
Brand: WILLIAMS & WHITE
Model: HIT#2273807
Year: Not listed
Message
Information

1000 TON WILLIAMS & WHITE 96" X 48" BED 4-POST HYDRAULIC PRESS: STOCK# 15313

Model
HIT#2273807
Stock #
15313
Year
Not specified
Condition
Used
Location
Ohio

CAPACITY ..................... 1000 TONS
BED LENGTH ................... 96"
BED WIDTH .................... 48"
DISTANCE BETWEEN COLUMNS ..... 72"
STROKE ....................... 42"
RAM SPEED (RAPID ADVANCE) .... 360" PER MINUTE
RAM SPEED (PRESSING SPEED) ... 14" PER MINUTE
DAYLIGHT (BOLTER TO PLATEN) .. 42" MAX
DAYLIGHT (BED TO PLATEN) ..... 51.75" MAX
BOLSTER THICKNESS ............ 9.75"
BOLSTER WITH T SLOTS ......... YES, 4" CENTERS
RAM PLATEN WITH HOLES ........ (200) 3/4" DIAMETER
PUMP ......................... DH-6025
HYDRO PNEUMATIC CUSHION ...... 250 TON
DIE CUSHION PAD .............. 59" X 36"
STROKE OF DIE CUSHION ........ 14"
Watch https://www.youtube.com/watch?v=bZJ-YYVgq0k&t=15s
