Working AreaDrilling capacity | 0.98 in | Table set up area | 16x22 in | T-slots, width | 0.6 in | Number of T-slots | 3 positions | Quill stroke | 8 in | Table stroke | 12 in | Feed Z-axis | (9) 0.0022 - 0.0709 in/R | Feed force, axial (max.) | 9 | Spindle nose-to-table distance (max.) | 29 in | Throat | 11 in | Vertical head travel | 8 in | HeadstockSpindle speed | (9) 50 - 2,000 rpm | Spindle Torque (max.) | 1,416 ft.lb. | Spindle taper | MT 3 | Drive CapacityMotor rating main drive | 3 Hp | Motor rating coolant pump | 0.1 Hp | Measures and WeightsFlow rate | 6.6 gal/min | Overall dimensions (length x width x height) | 38x34x93 in | Weight | 2,090 lbs |
- Box-column design provides high load capacity, and is torsion-proof and rigid
- Table and drill head can be moved individually for an optimum machining height
- 9-step feed and speed gears, with oil-bath lubrication
- High torque across the entire speed range
- Thread-cutting unit automatically reverses upon reaching the preset depth
- coolant system
- tapping unit
- work lamp
- operating tools
- operator instructions
|
