PRODUCT FEATURES

• ½ H.P. Spindle Motor;
• Precision ABEC 7 Angular Contact Ball Bearing Spindle;
• Spiral Mechanism Allows for Infinitely Variable Leads;
• Turntable Workhead Swivels 235 degree Allows for More Versatile Setups and Grinding of Radii;
• Offset Slide for Workhead Spindle Allows for Grinding of Convex or Concave Radii.

STANDARD ACCESSORIES

Items Numbered 1 through 18 on Catalog (including Wheelhead toothrest Assembly with extension bar,
Front stock support
Adjustable Tailstock
Diamond Dresser Holder Bracket
Wheel Guard with extension bar
Tooth Rest centering gauge
Allen Wrench set
Hook Wrench for Workhead
Leveling Pads
Tools
Straight cylindrical collets (1/8, 3/16, ¼, 5/16, 3/8, 7/16, ½, 5/8, ¾, 7/8, 1, 1-1/8, and 1-1/4) and #2, #3, and #4 Morse Taper taper collets,
5 grinding wheel flanges (4 standard and 1 extension flange)
Set of 4 index plates for Spiral Lead Mechanism (0, 8, 10, 12)

Large Cutter Radius Attachment
Grinding Wheel Flange (1/2” I.D.)

Spring Loaded Index Pawl for Workpiece Index Plates

Three Jaw Chuck for Workhead (4”)

Additional Straight Cylindrical Collets (Each)

Additional Index Plates for Spiral Lead Indexing Unit (Each)

Set of 3 Taper Collets (#5, #7, & #9)

Diamond Nib Dresser

Credit for standard 1/8” to 1-1/4” and #2 to #4 MT collets -$ 2,690.00

Set of three grinding wheels
BT40 collets set (inch 13 pieces)

GENERAL SPECIFICATIONS:
