EFI Vutek 5R+ Super Wide Roll-To-Roll LED UV Printer, 2019

The EFI VUTEk 5r+ is a super wide roll-to-roll LED UV printer designed for high-volume production of signage, banners, backlit graphics, vehicle graphics, and other flexible-media applications. It combines 18 printheads with 7 pL UltraDrop technology, up to 1,200 dpi resolution, and production speeds of up to 5,242 ft²/hr. The system supports roll-to-roll, free-fall, and multi-roll production and offers optional white, light-color, and clear-ink capabilities for expanded applications.

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Machine Type: Superwide Roll-to-Roll LED UV Printer Printing Technology: Piezo Drop-on-Demand Inkjet Printheads: 18 Printheads with 7 pL UltraDrop Technology Maximum Resolution: Up to 1,200 dpi True Resolution Maximum Print Width: 208″ (520 cm) Maximum Productivity: 5,242 ft²/hr (487 m²/hr) Standard Colors: CMYK Optional Colors: Light Cyan, Light Magenta, Light Black, White & Clear Ink Type: EFI UV LED-Curable Ink Media Handling: Roll-to-Roll, Free-Fall & Multi-Roll Multi-Roll Printing: Up to (3) 63″ (1.6 m) Rolls Media Utilization: Up to 300% improved media utilization Media Loading: 3″ Metal Bar for 5-Meter-Wide Media Motorized Winder: Optional Super-Duty Rewinder: Optional, supports rolls up to 1,750 lbs. (793 kg) White Ink: Optional White Ink Modes: White Only, White Under Color, White Over Color, C-W-C Backlit & C-W-B-W-C Blockout Seven-Color Printing: Optional UltraClear Coat: Optional Automatic Blockout Printing: Optional Automatic Backlit Printing: Optional X-Cutter: Optional Y-Slitter: Optional ID Backprint: Optional Media Edge Guards: Optional Media Spreaders: Included as Standard Wrinkle Analyzer: Optional Fiery RIP: EFI Fiery proServer Premium Compressed Air: 95 PSI / 6.5 bar, 4 CFM / 110 L/min Operating Temperature: 68–86°F (20–30°C) Humidity: 30–80% Non-Condensing Optimal Humidity: 50–80% Non-Condensing Machine Weight: Approximately 12,125 lbs. (5,500 kg) Crated Weight: Approximately 15,432 lbs. (7,000 kg) Machine Height: 86.6″ (220 cm) Machine Width: 27′ 6.7″ (840 cm) Machine Depth: 61″ (155 cm) Electrical: 230/380 VAC, 3 Phase + N + PE, 32 Amp, 50/60 Hz Printing Power Consumption: Approximately 2.9 kW Peak Power Consumption: Approximately 5.7 kW LED UV Chiller: 3.6 kW Cooling Capacity Applications: Banners, Signage, Backlit Graphics, Vehicle/Fleet Graphics, Window Graphics, Outdoor Graphics & Flexible Media

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
