Tsugami SS207-5AX CNC Swiss Type Automatic Lathe – 2017 (w/ Laser)

Tsugami SS207-5AX CNC Swiss Type Automatic Lathe – 2017 (w/ Laser)

Name: Tsugami SS207-5AX CNC Swiss Type Automatic Lathe – 2017 (w/ Laser)
Brand: TSUGAMI
SKU: 115144
Availability: InStock

Brand

TSUGAMI

Location

Not specified

Specifications
Files & Videos

Disclaimer: All specifications and hours are approximate and for reference only, often based on manufacturer literature. Buyer must verify all details prior to purchase. Accessories shown are included only if listed on the invoice.

Equipped With:
Fanuc 31i-MB5 CNC Control with 10.4″ LCD
Simultaneous All Axes Control
250 Watt SPI Fiber Laser System
Parts Catcher with Exit Conveyor & Basket
40 Gallon Cutting Oil Tank with Coolant Level Detector
Main Spindle Collet Chuck Unit (S&M TF25)
Back Spindle Collet Chuck Unit (S&M TF25)
Integral Motor-Driven Guide Bushing Unit
Spindle Cooling for Main, Sub & Guide Bushing Motors
Air/Oil Pressurized Driven Tool Gearbox Units
Air Pressurized Guide Bushing Unit
Main Spindle C-Axis with Brake
Sub Spindle C-Axis with Brake
Sub Spindle Air Blast
Door Interlock with Safety Switches
Centralized Lubrication System with Oil Level Detector
AC Servo Axes Control
Leveling Bolts & Pads
Machine Test Report
Parameter List
Hand Tools Included
One Complete Set of Manuals
(8) 1/2″ Square Turning Tool Positions (Main Spindle)
(3) Driven Tool Positions (Main Spindle, Cartridge Type)
(8) ID Tool Positions (Main or Sub Spindle)
(4) Static Back Working Stations (ID or Turning)
(2) Main Spindle Deep Hole Drill Positions (Max. 100 mm)
Up to 38 Tool Positions

Capacity:
Maximum Machining Diameter: 0.787″
Maximum Machining Length: 8.26″ (Chucking)
Main Spindle Speed: 200 – 10,000 RPM
Rotary Tool Spindle Speed: 200 – 8,000 RPM
Back Spindle Maximum Diameter: 0.787″
Back Spindle Front Ejection Length: 3.2″
Back Spindle Speed: 200 – 10,000 RPM
Rapid Traverse Rate: 32 m/min

Motors:
Main Spindle: 3 / 5 HP
Back Spindle: 2 / 3 HP
Rotary Tool: 1 HP
Coolant Pump: 0.5 HP

B1 Axis Tool Spindle:
Positioning Angle: 0° – 110°
Positioning Method: Servo Controlled
Number of Tool Positions: 6 (3 Main / 3 Sub)
Rotary Tool Speed: 5,000 RPM
Main Spindle Tool Collet: ER16
Sub Spindle Tool Collet: ER11

250W Fiber Laser:
Cooling System: Water Cooled
Laser Enclosure Classification: Class 1
Maximum Cutting Speed: 19.685″/sec
Wavelength: 1070 ± 10 nm
Frequency: 2 – 20 kHz
Pulse Width: 0 – CW
Laser Power: 25 – 250 W
Nozzle Standoff Adjustment: NC Controlled
Variable Gas Pressure: 5 – 350 psi
Number of Gas Connections: 2
Through Workpiece Coolant Pressure: 246 psi
Front-Fed Coolant Pressure: 1,000 psi

Tube Size Constraints:
Maximum Wall Thickness: 0.039″
Minimum Outside Diameter: 0.080″
Maximum Outside Diameter: 0.787″
Minimum OD to ID Ratio: 3:1

Optic Specifications:
Focal Length: f = 100 mm
Beam Reduction (Optional): 0.5 / 0.7
Beam Expansion (Optional): 1.4 / 2.0 / 2.8
Exchangeable Protection Glass: Yes
Cutting Nozzle Diameter: 1 mm – 3 mm

General:
Input Power: 6 kVA
Center Height: 39.37″
Machine Dimensions: 83.07″ × 47.24″ × 74.21″ High
Machine Weight: 7,260 lbs
