#3 WARNER & SWASEY UNIVERSAL NO 3 M-1200 TURRET LATHE: STOCK #81115

Name: #3 WARNER & SWASEY UNIVERSAL NO 3 M-1200 TURRET LATHE: STOCK #81115
Brand: WARNER & SWASEY
SKU: 81115
Availability: InStock

Brand

WARNER & SWASEY

Location

Not specified

REQUEST FINANCING

Specifications
Files & Videos

SERIAL ............................. 1702511
MODEL .............................. 1200
SWING OVER BED ..................... 15-3/8"
SWING OVER CROSS SLIDE ............. 7"
MAXIMUM TURNING LENGTH ............. 10"
COLLET CHUCK CAPACITY - ROUND ...... 1-1/2"
SQUARE CAPACITY .................... 1-1/16"
HEX CAPACITY ....................... 1-5/16"
SPINDLE THROUGH HOLE ............... 1-27/32"
SPINDLE NOSE TO TURRET FACE ........ 26-3/4"
SPINDLE SPEEDS ..................... (12) 67-1480 RPM
CARRIAGE CROSS FEEDS ............... (6) .0025-.026 IPR
CARRIAGE LONGITUDINAL FEEDS ........ (6) .003-.030 IPR
TURRET FEEDS ....................... (6) .003-.030 IPR
FLANGE TOOL HOLDER & ADJUSTABLE TOOL HOLDER ... YES
COOLANT CHIP PAN ................... YES
MOTOR HORSEPOWER ................... 5
