Doosan DNM-5700S CNC Vertical Machining Center – 2018 15,000 RPM Mill

Brand
DOOSAN
Category
Machining Centers
Type
Machining Centers, Vertical
Model
Doosan DNM-5700S
Stock #
115125
Year
2018
Condition
Not specified

Location

Not specified
REQUEST FINANCING

Disclaimer: All specifications and hours are approximate and for reference only, often based on manufacturer literature. Buyer must verify all details prior to purchase. Accessories shown are included only if listed on the invoice.

Equipment is sold AS-IS, WHERE-IS. All sales are final.

Make: Doosan
Model: DNM-5700S
Year: 2018
Condition: Used – Excellent
Equipped With:
Doosan-Fanuc i Series CNC Control
15,000 RPM High Speed Spindle
40 Station High Speed Automatic Tool Changer
Renishaw Probing System  (Probe Included)
Tool Presetter
CAT-40 Taper Spindle
1654 IPM Fast Rapids Traverse Rate
USB Drive
PCMCIA Card Slot
MPG Handwheel Control
Rigid Tapping
Coolant System
LNS Turbo Chip Conveyor
Travels:
X-Axis: 41.3″
Y-Axis: 22.4″
Z-Axis: 20.1″
Rapid Traverse Rates X & Y Axis: 1654 IPM
Rapid Traverse Rates Z Axis: 1417 IPM
Table:
Length: 51.2″
Width: 22.4″
Number of Std T-Slots: 4
T-Slot Width: 4.9″ x 0.7″
Max Weight on Table: 1764 lbs
Spindle:
Taper Size: CAT-40
Speed Range: 15,000 RPM
Spindle Power: 25 HP
Automatic Tool Changer:
Capacity: 40 Station Side Mounted
Max Tool Weight: 17.6 lbs
Max Tool Dia: 3.1″ -4.9″
Max Tool Length: 11.81″
Tool Changing Time : 1.2 Seconds
General:
Air Required: 80 psi, 4 scfm
Power: 220v / 35 kva / 3-Phase
Overall Dimensions: 122.4″ x 95″ x 117.5″ High
Weight:  14,330 lbs
