2012 MORI SEIKI NLX2500 SY/700
Brand
Category
Type
Model
NLX2500 SY/700
Stock #
Not specified
Year
2012
Condition
Excellent
Location
East Sussex, United Kingdom
|
Brand : MORI SEIKI
Model : NLX2500 SY/700 Year : 2012 Serial Nr: NL254120810 TECHNICAL DETAILS - Number of spindles : 2 - Number of turrets : 1 - Number of axes : 6 MAIN SPINDLE - Spindle nose : A2-8 - Max. bar diameter : 80 [mm] - Spindle power : 18,5 [kW] - Spindle speeds : 4.000 [rpm] - Max. turning diameter : 366 [mm] - C axis indexing precision : 0,001 [°] TURRET - Number of positions : 12 - Number of motorized positions : 12 - X/Z stroke : 260 x 795 [mm] - Y stroke : +/- 50 [mm] - Live tools speed : 6.000 [rpm] - Live tools power : 5,5 [kW] COUNTER-SPINDLE - Spindle nose : A2-5 - Max. bar diameter : 43 [mm] - Max. turning diameter : 190 [mm] - Spindle power : 11 [kW] - Spindle speeds : 6.000 [rpm] - C axis indexing precision : 0,001 [°] - Travel : 734 [mm] POWER SUPPLY - Supply voltage : 200 [V] - Total installed power : 41 [kVA] WEIGHT & DIMENSIONS : 1730 - Machine floor space : 4.414 x 2.370 [mm] - Machine height : 2.115 [mm] - Machine weight : 6.360 [kg] MACHINE HOURS - Number of hours under power : 34.552 [h] - Number of working hours : 11.420 [h] EQUIPMENT - CNC : MORI M730BM (Mitsubishi) - Interactive programming : MAPPS 4B - Interface : USB / RJ45 - Tool probe : Marposs - 3 colors status lamp - Tailstock function - Coolant tank - Chips conveyor - Parts catcher - Bar loader : LNS Quick Load Servo 3 (2011) - Chuck 3 jaws : KITAGAWA BB210 - Chuck 3 jaws : KITAGAWA B206 - Number of fixed tool holders : 4 - Number of turning tool holders : 2 - Electric transformer : 400 /200 [V] Technical details without warranty, just for information. Should technical documents be available, the machine will be delivered along with CDROM PDF Files. RD Machine Outils - SAS au capital de 1.250.000 Euros - Membre de l'Association Européenne des Marchands de Machines Outils |
