2011 Nakamura Tome Super NTMX Multi-Tasking CNC Lathe For Sale
Brand
Category
Model
Super NTMX
Stock #
15289
Year
Not specified
Condition
Used
Location
Michigan
| CNC Control | yes |
| Type Of CNC Control | Fanuc Series 31-Model A5 |
| # Axis | 9 |
| Turning Diameter | 8.66 inches |
| Center Distance | 38.58 inches |
| Chuck Size | 6 inches |
| Bar Capacity | 2 inches |
| X Axis Travel | 22.44 inches |
| X2 Travel | 5.14 inches |
| Z Axis Travel | 51.06 inches |
| Z2 Travel | 25.9 inches |
| Y-Axis Travel | 7.86 (+/- 3.94") |
| B Axis Travel (Sub Spindle) | 30.3 inches |
| B-axis Indexing | 190° (+/- 95°) |
| C1/C2 Axis Index | 0.001° |
| Rapid Traverse Rate (X/Y/Z) | 1181/630/1574 ipm |
| Y Axis | yes |
| Spindle Nose | A2-5 |
| Spindle Speed | 5,000 rpm |
| Main Motor | 15 hp |
| Sub Spindle | yes |
| Sub Spindle Chuck Size | 6 inches |
| Sub Spindle Speed | 5,000 rpm |
| Sub Spindle Motor | 15 hp |
| Live Tooling | yes |
| Milling Spindle Taper | CAPTO C4 |
| Live Tooling Speed | 12,000 rpm - Milling Spindle |
| Live Milling Motor | 10 hp |
| Tailstock (Yes/No) | no |
| ATC Capacity | 2 x 24 Stations |
| Number Of Turrets | 1 |
| Turret Capacity | 24 |
| Machine Dimensions | 190" x 165" x 104" - Floor Space w/Chip Conveyor |
| Machine Weight | 32000 pounds |
|
- Fanuc Series 31-Model A5 CNC Control
- Milling Spindle (CAPTO C4) - Dual 24 Station Tool Changers - Chip Conveyor - Coolant Tank & Pump - Lower Turret (24 Stations) - Live Tooling (Milling Spindle - 12,000 rpm) - Y Axis Capabilities - Sub Spindle |
|
