135 TON X 10' NIAGARA HYDRAULIC PRESS BRAKE: STOCK #80290
Brand
Category
Model
Not specified
Stock #
80290
Year
Not specified
Condition
Not specified
Location
Not specified
|
SERIAL NUMBER ......................... P54154 MODEL ................................. HBM-135-8-10 CAPACITY .............................. 135 TONS LENGTH OF BED & RAM ................... 10' DISTANCE BETWEEN HOUSINGS ............. 8'6" STROKE ................................ 7" OPEN HEIGHT ........................... 15" CLOSED HEIGHT ......................... 7" DEPTH OF THROAT ....................... 7" RAM SPEED – RAPID ADVANCE ............. 127 IPM RAM SPEED – NORMAL PRESS .............. 64 IPM RAM SPEED – AUTO BACK BAND ............ 20 IPM RAM SPEED – RAPID RETURN .............. 127 IPM CNC BACK GAUGE ........................ AUTOMEC 99 FLOOR TO BED .......................... 33-1/2" PRESS BRAKE CONTROLS .................. INCH-SINGLE-HAND-FOOT BED & RAM MACHINED FOR ANGLES ......... YES ELECTRIC FOOT TRIP / PALM BUTTON ...... YES FLOOR STANDING ........................ YES HYDRAULIC MOTOR HORSEPOWER ............ 20 |
