Platter
Platter Diameter: 6.30 In
Max Weight On Platter: 110 Lb
Part Swing Max: 17.5 In
Number Of Std T-Slots: 6 @ 60°
All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Spindle – A (Tilt) Max Speed: 80 °/Sec Torque (Continuous): 150 Ft-Lbf Backlash: 30 Arc-Sec Gear Ratio: 63:1 Timing: 2:1 Brake Torque @ 100 Psi: 200 Ft-Lbf All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Spindle – B (Rotary) Max Speed: 80 °/Sec Torque (Continuous): 100 Ft-Lbf Runout Max: 0.0005 In Backlash: 30 Arc-Sec Gear Ratio: 63:1 Timing: 2:1 Brake Torque @ 100 Psi: 100 Ft-Lbf All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Indexing – A (Tilt) Max Rotation/Step: ± 120 ° Resolution: 0.001 ° Accuracy (±): ± 15 Arc-Sec Repeatability: 10 Arc-Sec All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Indexing – B (Rotary) Max Rotation/Step (With Rotary Control): 999.999 ° Resolution: 0.001 ° Accuracy (±): ± 15 Arc-Sec Repeatability: 10 Arc-Sec All specifications are assumed to be correct but must be confirmed by the purchasing entity.,General Operating Temp (Max Ambient): 100 °F All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Air Requirements Air Pressure Max: 150 Psi All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Dimensions – Shipping Export Crate: 49.0 In X 21.0 In X 25.0 In Weight: 520 Lb All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Equipped With: 4th and 5th Axis Drives All specifications are assumed to be correct but must be confirmed by the purchasing entity. |
