150 TON AIDA GAP PRESS: STOCK #80181
Brand
Category
Type
Model
null
Stock #
80181
Year
Not specified
Condition
Not specified
Location
Not specified
|
SERIAL NUMBER ........................ 10115-0098 MODEL ................................ FP XGC-150 SU YEAR NEW ............................. 1983 CAPACITY ............................. 150 TON STROKE OF SLIDE ...................... 7.8" SHUT HEIGHT, SDAU (OVER BOLSTER) ..... 15.7" ADJUSTMENT POWER ..................... 3.3" AREA OF BED (T-SLOTTED) .............. 24.8" X 48.8" AREA OF RAM (T-SLOTTED) .............. 26.3" X 19.6" STROKES PER MINUTE ................... 45 SPM BED BOLSTER (T-SLOTTED) .............. 24.8" X 48.8" X 5" WIDTH OF HOLE THROUGH BACK ........... 26.5" FLOOR TO TOP OF BOLSTER .............. 37" AIR CLUTCH AND BRAKE ................. YES AIR COUNTERBALANCES .................. YES SINGLE, INCHING & CONTINUOUS ......... YES DUAL PALM BUTTONS .................... YES ONE SHOT LUBE ........................ YES ADJUSTMENT MOTOR HP .................. 1/4 MAIN DRIVE MOTOR HP .................. 10 |
