110 TON AIDA MODEL C 11-2 GAP FRAME PRESS: STOCK #80183
Brand
Category
Type
Model
0110
Stock #
80183
Year
Not specified
Condition
Not specified
Location
Not specified
|
SERIAL NUMBER ........................ 00211-5609 MODEL ................................ NC1-112 YEAR NEW ............................. 1983 CAPACITY ............................. 110 TON STROKE OF SLIDE ...................... 7.0" SHUT HEIGHT, SDAU (OVER BOLSTER) .... 13.7" ADJUSTMENT POWER ..................... 3.3" AREA OF BED (T-SLOTTED) .............. 27" X 24.5" AREA OF RAM (T-SLOTTED) .............. 20.5" X 24.5" STROKES PER MINUTE ................... 50 SPM BED BOLSTER (T-SLOTTED) .............. 27" X 24.5" X 5" WIDTH OF HOLE THROUGH BACK ........... 26" AIR CLUTCH AND BRAKE ................. YES AIR COUNTERBALANCES .................. YES AIR CUSHION .......................... YES SINGLE, INCHING & CONTINUOUS ......... YES DUAL PALM BUTTONS .................... YES ONE SHOT LUBE ........................ YES ADJUSTMENT MOTOR HP .................. 1/4 MAIN DRIVE MOTOR HP .................. 10 |
