2013 MORI SEIKI NHX4000

Product Specifications

• Model: Mori Seiki NHX4000

• Year: 2013

• Machine Type: Horizontal Machining Center

• X-Axis Travel: 22.0 inches

• Y-Axis Travel: 22.0 inches

• Z-Axis Travel: 25.9 inches

• Spindle Motor Power: 25 HP

• Spindle Speed: Up to 12,000 RPM

• Spindle Taper: HSK-63

• Tool Changer Capacity: 40 tools (Automatic Tool Changer)

• Pallet Size: 15.7 in x 15.7 in (400 mm x 400 mm)

• Control: MAPPS / Fanuc-based CNC system (varies by configuration)

Key Features

• High-rigidity frame for excellent stability during heavy cutting

• 12,000 RPM spindle supports high-speed, precision machining

• HSK-63 taper ensures rigidity and repeatability in tooling

• 40-position ATC enables quick tool changes for reduced cycle time

• Compact pallet size (15.7″) for space-efficient multi-part setups

• Advanced MAPPS control interface for streamlined programming and diagnostics

• Ideal for high-mix, low-volume or production work

Applications

• Precision component manufacturing in automotive and aerospace sectors

• High-speed milling of molds, dies, and complex aluminum parts

• Job shops requiring fast changeovers and dependable repeatability

• Medical and electronics parts with tight tolerances

• Multi-part batch runs using the horizontal pallet changer system
