Rated Tonnage: 175 Ton
Tonnage at Full Forming Speed: 190 Ton
Bed & Ram Length (OAL): 8 feet (96″)
Distance Between Housings: 6′ 6¾” (78.75″)
Max Bending Capacity: 6′ 3″ × 3⁄8″ mild steel
Stroke Length: 10″
Open Height: 17″
Closed Height: 7″
Throat Depth: 8″
Ram Speeds — Approach: 260 IPM
Ram Speeds — Forming: 1–65 IPM
Ram Speeds — Return: 1–290 IPM
Hydraulic Drive Motor: 25 HP
Estimated Weight: 19,500 lb
Control: AutoForm CNC
All specifications are assumed to be correct but must be confirmed by the purchasing entity. |
