Hardinge Conquest ST-216-B Twin Spindle CNC Lathe

Hardinge Conquest ST-216-B Twin Spindle CNC Lathe

Brand

HARDINGE

Location

Not specified

REQUEST FINANCING

Specifications
Files & Videos

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*

SKU:	112215
Make:	Hardinge
Model:	ST-216-B
Year:	2000
Serial:	159-16

Equipped With:
Fanuc 18T CNC Control
C Axis and Live Tools Capable
12000 RPM Main Spindle
Precision Hardinge 5/8″ Collet Spindle
MPG Control
Front access quick change guide bushings
12 Station Tool slide for front and back turning
Coolant System
Foot Switch
Spindle Cooler
Comes with lot of Collets

Capacity:
Max Bar Diameter: 5/8″ (16mm)
Max Turning Length: 10.35″

Travels:
X1 Axis Travel: 2.75″
Y1 Axis Travel: 7.50″
Z1 Axis Travel: 10.35″
Y2 Axis Travel: 9.00″
Z2 Axis Travel: 8.50″
Rapid Traverse X Axis: 1181 IPM
Rapid Traverse Z Axis: 1181 IPM

Spindle:
Main Spindle Indexing: 5°
Main Spindle Bore: 2.31″
Main Spindle Speed: 300-12000 RPM
Spindle Motor: 5 HP
Sub Spindle Indexing: 5°
Sub Spindle Bore: 2.31″
Sub Spindle Speed: 200-8000 RPM
Spindle Motor: 3 HP

Tools:
Turret Capacity: 12 Stations
Turret Index Time: 0.15 Second
Max. Tool Size: 0.8″ Square X 1.26″ Round

General:
Power: 45 kva, 220v / 3-Phase
Overall Dimensions: 90″ X 60″ X 80 ” High
Weight: 7500 lbs
