X|205"
Y|122"
Z|27.5"
Power|30 hp
RPM|3,500 RPM
# ATC|180
Taper|Cat 50
Table-W|102.36"
Table-L|197"
Control|CNC (Heidenhain iTNC 530)
Dimensions|504" x 248" x 187"
Weight|110,000 lbs
15" Color LCD
Vertical and Horizontal Machining Capability
Emana VGCI OP-4 Milling Head (2.5 Degrees)
Heidenhain Linear Scale Feedback System
Coolant Thru Spindle (290 psi)
Heidenhain TT-130 Auto Tool Length Measurement
Heidenhain TS-220 Touch Probe
180 Tool Magazine
Three Color Tower Light
Remote Manual Pulse Generator
Spindle Ram Size: 14.96" Square
Spindle Nose to Table Top: 5.59' - 33.15"
Rapid Traverse Rates (X & Y / Z): 480 / 393 IPM
Table Load Capacity: 44,000 lbs.
Rapid Traverse Rates: 390 IPM
Tool Change Time (T - T): 8 Seconds
Max Tool Diameter: 4.92" / 9.84"
Max Tool Length: 13.78'
Max Tool Weight: 44 lbs.
https://www.youtube.com/watch?v=wp_1rPPd10Y Watch the video
Location: Stratford, Ontario N5A 6S4, Canada
|
