CAPACITY:
Table Diameter 177.16"
Maximum Swing 216.53"
Maximum Turning Height 157.48"
Ram Dimensions 15.74" x 15.74"
Taper in Ram BT-50
Table Speeds, 2-Range 1 - 60 RPM
Table Weight Capacity 110,000 Lbs
Z-Axis Travel, Ram Stroke 78.74"
X-Axis Travel, Cross Travel 111.81"
W-Axis Travel, Rail Vertical 98.42"
Cutting Feed Rate, X/Z-Axes Up to 236.22 IPM
Rapid Traverse Rate, X/Z-Axes 236.22 IPM
Rapid Traverse Rate, W-Axis 19.68 IPM
Table Motor 174.33 HP
Approx. Machine Footprint 551.18" x 355.90"
Approx. Machine Height 433.07"
Approx. Machine Weight 352,000 Lbs



Equipped With:
Fanuc 31i-A CNC Control
177.16" Independent Manual 4-Jaw Chuck
12 Station Automatic Tool Changer
Double Column Design
Coolant System
Power Elevating Rail
Steel Sliding Way Covers
Splash Guard
Chip Conveyor
