10" X 50" SOUTHWESTERN TRAK CNC RAM TYPE VERTICAL MILLl: STOCK #78913
Brand
Category
Type
Model
K3
Stock #
78913
Year
Not specified
Condition
Not specified
Location
Not specified
|
SERIAL ........................ 98-02190 MODEL ........................ TRAK K3 CONTROL ......................... TRAH A G E 2 TABLE SIZE ...................... 10" x 50" TABLE TRAVEL (X) ................ 32" SADDLE TRAVEL (Y) ............... 16" VERTICAL HEAD TRAVEL (Z) ........ 23.5" QUILL TRAVEL .................... 5" SPINDLE TAPER ................... #40 NST SPINDLE NOSE TO TABLE ........... 0-24" SPINDLE CENTER TO COLUMN FACE ... 17.3" HEAD SWIVEL LEFT & RIGHT ........ 90 DEGREES SPINDLE SPEED RANGE ............. 70 TO 4,200 RPM QUILL FEEDS (3) ................. .002, .004, .006 IPR POWER DRAW BAR ... YES MAXIMUM WORKPIECE WEIGHT ........ 1,320 LBS LUBRICATION SYSTEM .............. AUTOMATIC SPINDLE MOTOR ................... 3 HP |
