Toyoda FH450S HMC, 2007- 450mm x 18 Pallet RGV, 494 ATC, Probing, CTS, Software Upgrade

X-Axis Travel: 23.62” (600 mm) Y-Axis Travel: 23.62” (600 mm) Z-Axis Travel: 23.62” (600 mm) Table Index: Full NC Table (360,000 Positions) Pallet Size: 17.7″ x 17.7″ (450 mm x 450 mm) RGV Pallet System: 18 Pallets Automatic Tool Changer: 494 Positions Spindle Speed: 12,000 RPM Spindle Taper: CAT#40 Spindle Motor: 30 HP Spindle Output Torque: 123 ft-lb (167 Nm) Rapid Feedrate (X/Y/Z axis): 1,968 ipm (50 m/min) Max Workpiece Swing: 24.80” (630 mm) Max Workpiece Height: 35.43″ (900 mm) Max Pallet Work Load: 880 lb (400 kg) Approx. Floor Space: 100″ x 243″ (2,520 mm x 6,159 mm) Machine Height: 125″ (3,160 mm) Standard Net Weight: 25,300 lb (11,500 kg)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,EQUIPPED WITH: Fanuc Series 31i (Model A) CNC Control 18 Pallet Linear Rail-Guided Vehicle Transfer System- 2 Work Set Stations 494 Tool Automatic Tool Changer Positions Coolant Through Spindle Probing Mist Filter Windows 10 Cell Controller Software- 2022 Upgrade

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
