2HP SHARP PROTO TRAK CNC RAM TYPE VERTICAL MILL: STOCK #78336

SERIAL ........................... 01126682

MODEL ............................ MP2

AREA OF TABLE .................... 42" X 9"

SPINDLE SPEEDS, VARIABLE ......... 60 TO 4500 RPM

SPINDLE FEEDS .................... .0015, .003, .005 IPR

LONGITUDINAL TABLE TRAVEL ........ 35"

CROSS TRAVEL ..................... 16.30"

VERTICAL KNEE TRAVEL ............. 15"

QUILL TRAVEL ..................... 5"

RAM TRAVEL ....................... 18.5"

POWER LONGITUDINAL TRAVEL ........ SERVO

POWER DRAW BAR ................... YES

DEPTH OF THROAT .................. 5" TO 28"

TAPER IN SPINDLE ................. R8

HEAD TILTS, FRONT/BACK ........... 45 DEGREE EITHER WAY

HEAD SWIVELS, LEFT/RIGHT ......... 90 DEGREE EITHER WAY

CNC CONTROL ............... ACURITE MP2

AUTO LUBE..................... YES

MOTOR ............................ 2 HORSEPOWER
