CAPACITY:

X-Axis Travel 82.67"
Y-Axis Travel 35.43"
Z-Axis Travel 33.46"
Table Size 94.48" x 35.43"
Table Weight Capacity 5,500 Lbs.
Spindle Speeds 6,000 RPM
Maximum Feed Rate (X&Y) 787.40 IPM
Maximum Feed Rate (Z) 708.66 IPM
Spindle Taper CAT #50
Spindle Nose to Table 3.93"-37.4"
Spindle Drive Motor 24.6 HP / 20 HP
Electrics 230/3/60
Machine Dimensions (w/ Chip Conveyor) . 244" x 165" x 146"Machine Weight 49,500 Lbs.

Equipped With:

Fanuc OiMF Plus CNC Control with 10.4" LCD Screen
Box Ways
Rigid Tapping
32-Position Automatic Tool Changer
Automatic Lubrication System
Fully Enclosure Splash Guard with Interlock Device
Telescoping Covers for X & Y Axis
Portable MPG
Chip Conveyor

Note:


Brand New Machine, Approx. 4-Month Delivery
1-Year Parts Warranty on Machine
2-Year Parts & Labor On CNC Control
